FUJI NXT III SMT Pick and Place Machine
FUJI NXT III
Quantity
FUJI NXT III SMT Pick and Place Machine
Company Profile:
Extension Company was established in 2009, a SMT electronic manufacturing service company.
Service customers involved in EMS electronics manufacturing products in various areas. Like smart phone, automotive electronics, earphones, air conditioners, computers and communication tools. These product's workshop planning, production management, quality control and efficiency improvement.
Extension providing SMT solutons including SMT line, SMT machine, SMT stencil printer, reflow oven, wave soldering machine, and THT insertion Machine.
Successful Experience:
Extension's Customer in 60 Countries Around the World
1. We have been helping customers to build a lot of new factories and increase productivity around the world.
2. We help customers solve machine production problems quickly.
3. Became the most reliable SMT partner for you.
For SMT Factory Setup or increase productivity, we can do for you:
1. We provide full SMT solution for You.
2. We provide continuous and reliable supply of spare parts.
3. We provide installation and training services for SMT line.
4. We have wealthy experience on SMT Factory Setup.
5. We can solve SMT problems for you.
FAQ:
Q: What we can do for you?
A: Total SMT Machines and Solution, professional Technical Support and Service.
Q: What brand of machines do you supply?
A: Famous brand. Such as FUJI, ASM, Panasonic, Samsung, JUKI, Yamaha, Heller, DEK, etc.
Q: What is your delivery date?
A. The delivery date is about 30 days after receipt of payment
Q: What your main customers?
A:OSRAM, HUAWEI, TESLA, Inventec, Samsung, Hisense, Foxconn
Q: Why choose us?
A: Leading SMT Supplier in China; Wealthy SMT experience; Professional after-sales service team.
Extension's exhibition moments：
Packaging:
Specification of FUJI SMT pick and place machine
| Item | FUJI NXT M3 III | FUJI NXT M6 III |
| Applicable PCB size (LxW) | 48 x 48 mm to 250 x 510 mm (double conveyor)* | 48 x 48 mm to 534 x 510 mm (double conveyor)* |
| 48 x 48 mm to 250 x 610 mm (single conveyor) | 48 x 48 mm to 534 x 610 mm (single conveyor) | |
*Double conveyors can handle PCBs up to 280 (W) mm. PCBs larger than 280 (W) mm must be produced by changing the double conveyor to single lane production mode. | *Double conveyors can handle PCBs up to 280 (W) mm. PCBs larger than 280 (W) mm must be produced by changing the double conveyor to single lane production mode. | |
| Part types | Up to 20 types of parts (calculated using 8 mm tape) | Up to 45 types of parts (calculated using 8 mm tape) |
| PCB loading time | For double conveyor: 0 sec (continuous operation) | |
| For single conveyor: 2.5 sec (transport between M3 III modules), 3.4 sec (transport between M6 III modules) | ||
| Supported parts | H24G: 0201 to 5 x 5 mm V12/H12HS : 0402 to 7.5 x 7.5 mm H08M : 0603 to 45 x 45 mm H08 : 0402 to 12 x 12 mm H04 : 1608 to 38 x 38 mm H04S/H04SF : 1608 to 38 x 38 mm H02/H02F/H01/0F : 1608 to 74 x 74 mm G04/G04F :0402 to 15 x 15 mm | Height : up to 2.0 mm Height : up to 3.0 mm Height : up to 13.0 mm Height : up to 6.5 mm Height : up to 9.5 mm Height : up to 6.5 mm Height : up to 25.4 mm Height : up to 6.5 mm |
| Module width | 320 mm | 645 mm |
| Machine dimensions | L: 1295 mm (M3 III x 4, M6 III x 2) / 645 mm (M3 III x 2, M6 III) W: 1900.2 mm, H: 1476 mm | |
